Vortex Diamondback 3.5-10×50-Dead-Hold BDC (MOA)

The Diamondback – loaded with features! First, the solid
one-piece aircraft-grade aluminum alloy construction makes the Diamondback
riflescope virtually indestructible and highly resistant to magnum recoil.
Argon purging puts waterproof and fogproof performance on the agenda, and
advanced fully multi-coated optics raise an eyebrow when crystal clear,
tack-sharp images appear in the crosshairs. Look for all this and more in a
riflescope you’d expect to cost quite a bit more-but doesn’t. We can live with
that.

Diamondback 3.5-10×50-Dead-Hold BDC (MOA) Dimensions (in
inches)



Lengths
L1	L2	L3	L4	L5	L6
12.5	2.0	2.1	5.4	3.9	3.1



Heights
H1	H2
2.29	1.69



Included in the Box

• Removable
  lens covers

• Lens
  cloth

Magnification 3.5-10x

Objective Lens Diameter 50 mm

Eye Relief 3.3 inches

Field of View 35.8-13.5 ft/100 yds

Tube Size 1 inch

Turret Style Capped

Adjustment Graduation 1/4 MOA

Travel Per Rotation 15 MOA

Max Elevation Adjustment 65 MOA

Max Windage Adjustment 65 MOA

Parallax Setting 100 yards

Length 12.5 inches

Weight 16.2 oz

Product Manual (PDF) Download

Reticle Manual (PDF) Download
